Performance
|
|
|
Standard Specifications
|
|
|
Platform Height
|
34 ft 5 in
|
|
DC Power
|
24V DC
|
|
Horizontal Outreach
|
|
Batteries
|
4 x 6V 220 amp - hr
|
|
Working Outreach
|
20 ft 2 in
|
|
Gasoline Engine (Optional)
|
Honda GX 270 - 9 hp
|
|
Centerline to Platform Edge
|
18 ft 9.5 in
|
|
Tires
|
205/75 R14 Pneumatic
|
|
From Outrigger Pad Edge
|
13ft 6 in
|
|
Standard Features
|
|
|
Up and Over Height
|
15 ft
|
|
Telescopic Upper Boom
|
Proportional Controls
|
|
Swing
|
410 Degrees Non-Continuous
|
|
110V-AC Receptable in the Platform
|
Auto-Leveling Hydraulic Outriggers
|
|
Platform Capacity
|
500 lb
|
|
Motion Alarm
|
Tilt Alarm/Indicator Light
|
|
Platofrm Capacity W/Rotator
|
440 lb
|
|
Hourmeter
|
Four 6V Amp-Hour Batteries
|
|
Material Hook Capacity
|
500 lb
|
|
Battery Condition Indicator
|
Parking Brake
|
|
Platform Rotator (optional)
|
90 Degrees Manual
|
|
2 in Hitch with Adjustable Height Coupler
|
Standard Air and Water Line to Platform
|
|
Weight
|
3,400 lb |
|
Accessories & Options
|
|
|
Leveling Capacity
|
11 Degrees
|
|
Platform Rotator
|
Material Hook
|
|
Towing Speed Rating
|
65 mph
|
|
Drive and Outrigger Set
|
Platform Mounted Glass/Panel Tray
|
|
Tongue Weight
|
242 lb
|
|
Non-Making Outrigger Pads
|
Full Size Spare Tire
|
|
|
|
|
Flashing Amber Beacon
|
3000 Watt Honda Generator
|
