Gear Drive Transmission |
HST |
|
2WD |
4WD |
4WD |
| Engine |
|
| Type |
Direct injection, vertical, water-cooled 4 cycle diesel
|
| Engine Gross Power |
37.5 HP
|
| Engine Net Power |
36.3
|
| PTO Power |
32.1 HP
|
30.6 HP
|
| No. Of Cylinders |
3
|
| Bore and Stroke |
3.4 x 4 cu in
|
| Total Displacement |
111.4 in
|
| Rated Speed |
2700 rpm
|
| Battery |
12 V, RC: 110 min, CCA: 580 A
|
| Alternator |
12 V, 40 A
|
| Fuel Tank Capacity |
11.1 gal
|
| PTO
|
|
| Rear PTO Type |
Live-Continuous Running
|
Live with Overunning Clutch
|
| PTO/Engine Speed |
540/2425
|
540/2580
|
| Hydraulic |
|
| Live Control Type |
Position Control
|
| Pump Capacity Main |
6.3 gpm
|
| Pump Capacity PS |
3.8 gpm
|
| 3-Point Hitch |
Category 1
|
| Lift Capacity at Lift Points |
1985 lbs
|
| Lift Capacity at 24 in Behind Lift Points |
1433 lbs
|
| System Pressure |
165 kgf/cm2
|
| Fuel Tank Capacity |
11.1 gal
|
| Traveling System |
|
| Transmission |
Gear Skirt with synchronized shuttle, 8 forward and 8 reverse
|
Hydrostatic transmission 3 range speed
|
| Steering |
Integral Type Power Steering
|
| Brake |
Mechanical, wet disk type
|
| Clutch |
Dry Type Dual Stage
|
Dry Single
|
| Tire Size |
5.00 - 15 / 11.2 - 24
|
7.2-16 / 11.2 -24
|
| Traveling Speed |
Forward
1.1 mph - 13.2 mph
Reverse
1.1 mph - 13.1 mph
|
Forward
0 mph - 14.1 mph
Reverse
0 mph - 12.7 mph
|
| Dimensions |
|
| Overall Length |
110.6 in
|
107.9 in
|
| Overall Width |
55.1 in
|
| Overall Height |
91.7 in
|
| Wheelbase |
63.3 in
|
| Min. Ground Clearance |
13.6 in
|
13.4 in
|
| Min. Ground Clearance |
13.6 in
|
13.4 in
|
| Tread Front Tire |
41.3 in
|
43.1 in
|
| Tread Rear Tire |
43.8 in /47.1 in
|
| Min. Turning Radius |
7.9 feet
|
8.2 feet
|
| Weight |
2590 lbs
|
2767 lbs
|
2778 lbs
|
